F20

F 20 Cab Filtration Over Pressure Unit

The UK’s No one company for hazardous air cab filtration overpressure systems

We provide clients with the highest possible level of service anywhere in the area dedicated to finding solutions to customers requests delivering clean air for operator protection.

The Arctic Air F20 cab filtration over pressure system is a cylindrical compact yet high in capacity system making it ideal for fender or side step mounting on loading shovels,fork trucks ,self propelled sprayers and many other types of machinery.

The cab filtration system is manufactured from 304 grade stainless steel and dependant on filter capacity comes with either a short or long filter cover held in place with a single hand wheel nut to enable quick filter replacement without the need for tools.

The new 4000 series system controller has  state of the art technology inside facilitating a comprehensive level of information displayed on the large clear display in a variety of languages.

Plug and play gas sensor monitoring is also possible inside and outside the cabin (as an option)

The F20 cab filtration system has been designed to comply with the New ISO 23875 standards further enhancing operator safety particularly in the mining industry.

We will be pleased to discuss your requirements, just click on the contact us button below.

F 20 Technical data.

Diameter. 350mm

Height. 430 mm (830 mm with high cap)

Weight. 13 kg without filters

Voltage. 12 and 24 volts

Controller. 4000 series

Max Pressure. 440 Pascals

Dust Filtration. P1 (ISO16890/P3EN1822 H13)

Gas Filtration 3.3 up to 10Kgs Active carbon
EN 12941/ EN 14387

Industry ISO23875/NEN4444/
Standards CROW400/INRS

F4000 series controller with selectable language and dealer level selectable pressure alarm levels.

New F4000 series cabin pressure controller which supports plug and play gas monitoring inside and outside the cab

NEW F4000 series  inteligent cabin pressure controller.

Graphically displays gas sensor safety limits and supports filter recognition,once the filter installation date is programmed into the controller it will warn the operator when the running time has expired.
